☆ INTRODUCTION
DERADAR-24G is the first version of the demo board targeting at 24GHz radar module from Good Display. It also can be used for 60GHz radar module (IR24VDA / IR24BDA / IR60BH1A). It is designed for better user experience like more convenient and direct experiencing of the radar module performance and faster connecting of wireless general module. Since both the radar module and communication module support Plug/Unplug mode, users can compose their own service platform at will. Due to the extra MCU board docking port, users can also via their own MCU to communicate with the radar and wireless module respectively.
Relevant manual about this product on Library or you could go to our official website (www.iflabel.com), contact us please.
*Note: State Indicators will not turn on when connecting 60G radar sensor.
☆ THE ABOVE PRICE INCLUDE
1) 24G Biological Perception RadarDemo Evaluation Board, DERADAR-24G
☆ PRODUCT FUNCTIONS
● Manufacturer embedded engineer
Use DERADAR-24G to perform initial development and debugging of embedded program
● Maker
Use DERADAR-24G to realize demo of hardware products and develop projects along with communication module.
● Technology enthusiasts Use DERADAR-24G for quick experiencing the theory, output parameters and interface protocol of radar.
☆ DETAILS
☆ HARDWARE COMPOSITION
● Power supply input mode
Micro USB – DC 5.0V ≥500mA
● Output voltage
DC 5.0V , 3.3V
● TTL serial port
Supports to be the debugging port
● Interface of function board
24G radar moduleR24VD1B , communication board for wireless module , MCU board, light perception board
● Other
1 slide switch, 4 indicators
☆ INSTRUCTION OF HARDWARE
☆ INSTALLATION INSTRUCTIONS
● Fix the product on the top of the house (2.2-2.7m) by drilling holes and embedding expansion screws, or paste it to the wall;
● Push in the expansion screw to fix the base plate of the mounting bracket;
● Align the radar base with the mounting bracket clip and fix the radar in the rotating direction;
● Device power, distribution network, connect App.
